Camera

Image Sensor

1/2.8 inch CMOS

Effective Pixels

1920 (H) × 1080 (V), 2MP

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/3s–1/100000s
NTSC: 1/4s–1/100000s

S/N Ratio

>65 dB

Minimum Illumination

Color: 0.004LuxLux/F2.4
Black & White: 0.0004LuxLux/F2.4

Lens

Lens Type

Fixed-focal

Mount Type

M12

Focal Length

2.8 mm

Max. Aperture

F2.5

Angle of View

130° × 110° × 59° (diagonal x horizontal x vertical)

Iris Type

Fixed iris

Close Focus Distance

0.5 m (1.6 ft)

DORI Distance

D: 41.4 m (135.8 ft); O: 16.6 m (54.5 ft); R: 8.3 m (27.2 ft); I: 4.1 m (13.4 ft)

Video

Frame Rate

CVI:
PAL: 1080P@25fps, 720P@25/50fps
NTSC: 1080P@30fps, 720P@30/60fps
AHD: PAL: 1080P@25fps, 720P@25fps
NTSC: 1080P@30fps, 720P@30fps
TVI: PAL: 1080P@25fps, 720P@25ps
NTSC: 1080P@30fps, 720P@30ps
CVBS: PAL: 960 × 576H
NTSC: 960 × 480H

Resolution

1080P (1920 × 1080); 720P (1280 × 720); 960H (704 × 576/704 × 480)

Day/Night

Auto switch by ICR

BLC

BLC/HLC/WDR

WDR

120 dB

White Balance

Auto; manual

Gain Control

Auto; manual

Noise Reduction

3D NR

Smart IR

Yes

Electronic Defog

Yes

Digital Zoom

4 ×

Mirror

Off/On

Privacy Masking

Off/On
